Application Field:

The CDS-B/C series conventional lathes, developed by our company in collaboration with renowned global lathe manufacturing enterprises, are user-friendly general-purpose lathes. They feature a popular angular flat design with spacious front and rear legs. The bed guide rails have undergone surface high-frequency quenching and grinding processes, achieving a quenching hardness of G50. The headstock gearbox has undergone high-frequency quenching of the gear teeth and precision gear grinding, with gear precision reaching levels 6 to 7. This machine can process materials such as steel, cast iron, non-ferrous metals, and non-metallic materials. Parts processed on this machine can achieve a dimensional accuracy of IT7 and a surface roughness of 1.6.

Machine Features:

1. Large Spindle Bore: B-type with 82mm, C-type with 105mm.

2. High Spindle Speed: The spindle system is dynamically balanced, allowing for high rotational speeds and comprehensive adaptability to tooling techniques.

3. High Rigidity: The main body of the machine tool is made entirely of resin-bonded high-phosphorus castings, and the structure of the main body of the machine tool is made more rational through finite element analysis and optimization.

4. Aging Treatment for Bed Body, High-Frequency Quenching for Guide Rails: Enhances the machine tool's longevity.

5. Precision Grinding for Bed Guide Rails: Ensures high precision along the entire length of the guide rails.

6. Vertical Lead Screw Equipped with Metal Protective Cover: Enhances the personal safety of operators.

7. Rapid Traverse Mechanism in Both Vertical and Horizontal Directions on the Carriage: Makes the operation of the machine tool more convenient and efficient for operators.
